Refurbishing my Macintosh Plus

Somewhere in the mid to late 1990s I picked myself up a Macintosh Plus for the sum of $60AUD. At that time there were still computer Swap Meets where old and interesting equipment was around, so I headed over to one at some point (at the St Kilda Town Hall if memory serves) and picked myself up four 1MB SIMMs to boost the RAM of it from the standard 1MB to the insane amount of 4MB. Why? Umm… because I could? The RAM was pretty cheap, and somewhere in the house to this day, I sometimes stumble over the 256KB SIMMs as I just can’t bring myself to get rid of them.

This upgrade probably would have cost close to $2,000 at the system’s release. If the Macintosh system software were better at disk caching you could have easily held the whole 800k of the floppy disk in memory and still run useful software!

One of the annoying things that started with the Macintosh was odd screws and Apple gear being hard to get into. Compare to say, the Apple ][ which had handy clips to jump inside whenever. In fitting my massive FOUR MEGABYTES of RAM back in the day, I recall using a couple of allen keys sticky-taped together to be able to reach in and get the recessed Torx screws. These days, I can just order a torx bit off Amazon and have it arrive pretty quickly. Well, two torx bits, one of which is just too short for the job.

My (dusty) Macintosh Plus

One thing had always struck me about it, it never really looked like the photos of the Macintosh Plus I saw in books. In what is an embarrassing number of years later, I learned that a lot can be gotten from the serial number printed on the underside of the front of the case.

So heading over to the My Old Mac Serial Number Decoder I can find out:

Manufactured in: F => Fremont, California, USA
Year of production: 1985
Week of production: 14
Production number: 3V3 => 4457
Model ID: M0001WP => Macintosh 512K (European Macintosh ED)

Your Macintosh 512K (European Macintosh ED) was the 4457th Mac manufactured during the 14th week of 1985 in Fremont, California, USA.

Pretty cool! So it is certainly a Plus as the logic board says that, but it’s actually an upgraded 512k! If you think it was madness to have a GUI with only 128k of RAM in the original Macintosh, you’d be right. I do not envy anybody who had one of those.

Some time a decent (but not too many, less than 10) years ago, I turn on the Mac Plus to see if it still worked. It did! But then… some magic smoke started to come out (which isn’t so good), but the computer kept working! There’s something utterly bizarre about looking at a computer with smoke coming out of it that continues to function perfectly fine.

Anyway, as the smoke was coming out, I decided that it would be an opportune time to turn it off, open doors and windows, and put it away until I was ready to deal with it.

One Global Pandemic Later, and now was the time.

I suspected it was going to be a capacitor somewhere that blew, and figured that I should replace it, and probably preemptively replace all the other electrolytic capacitors that could likely leak and cause problems.

First thing’s first though: dismantle it and clean everything. First, taking the case off. Apple is not new to the game of annoying screws to get into things. I ended up spending $12 on this set on Amazon, as the T10 bit can actually reach the screws holding the case on.

Cathode Ray Tubes are not to be messed with. We’re talking lethal voltages here. It had been many years since electricity went into this thing, so all was good. If this all doesn’t work first time when reassembling it, I’m not exactly looking forward to discharging a CRT and working on it.

The inside of my Macintosh Plus, with lots of grime.

You can see there’s grime everywhere. It’s not the worst in the world, but it’s not great (and kinda sticky). Obviously, this needs to be cleaned! The best way to do that is take a lot of photos, dismantle everything, and clean it a bit at a time.

There’s four main electronic components inside a Macintosh Plus:

  1. The CRT itself
  2. The floppy disk drive
  3. The Logic Board (what Mac people call what PC people call the motherboard)
  4. The Analog Board

There’s also some metal structure that keeps some things in place. There’s only a few connectors between things, which are pretty easy to remove. If you don’t know how to discharge a CRT and what the dangers of them are you should immediately go and find out through reading rather than finding out by dying. I would much prefer it if you dyed (because creative fun) rather than died.

Once the floppy connector and the power connector is unplugged, the logic board slides out pretty easily. You can see from the photo below that I have the 4MB of RAM installed and the resistor you need to snip is, well, snipped (but look really closely for that). Also, grime.

Macintosh Plus Logic Board

Cleaning things? Well, there’s two ways that I have used (and considering I haven’t yet written the post with “hurray, it all works”, currently take it with a grain of salt until I write that post). One: contact cleaner. Two: detergent.

Macintosh Plus Logic Board (being washed in my sink)

I took the route of cleaning things first, and then doing recapping adventures. So it was some contact cleaner on the boards, and then some soaking with detergent. This actually all worked pretty well.

Logic Board Capacitors:

  • C5, C6, C7, C12, C13 = 33uF 16V 85C (measured at 39uF, 38uF, 38uF, 39uF)
  • C14 = 1uF 50V (measured at 1.2uF and then it fluctuated down to around 1.15uF)

Analog Board Capacitors

  • C1 = 35V 3.9uF (M) measured at 4.37uF
  • C2 = 16V 4700uF SM measured at 4446uF
  • C3 = 16V 220uF +105C measured at 234uF
  • C5 = 10V 47uF 85C measured at 45.6uF
  • C6 = 50V 22uF 85C measured at 23.3uF
  • C10 = 16V 33uF 85C measured at 37uF
  • C11 = 160V 10uF 85C measured at 11.4uF
  • C12 = 50V 22uF 85C measured at 23.2uF
  • C18 = 16V 33uF 85C measured at 36.7uF
  • C24 = 16V 2200uF 105C measured at 2469uF
  • C27 = 16V 2200uF 105C measured at 2171uF (although started at 2190 and then went down slowly)
  • C28 = 16V 1000uF 105C measured at 638uF, then 1037uF, then 1000uF, then 987uF
  • C30 = 16V 2200uF 105C measured at 2203uF
  • C31 = 16V 220uF 105C measured at 236uF
  • C32 = 16V 2200uF 105C measured at 2227uF
  • C34 = 200V 100uF 85C measured at 101.8uF
  • C35 = 200V 100uF 85C measured at 103.3uF
  • C37 = 250V 0.47uF measured at <exploded>. wheee!
  • C38 = 200V 100uF 85C measured at 103.3uF
  • C39 = 200V 100uF 85C mesaured at 99.6uF (with scorch marks from next door)
  • C42 = 10V 470uF 85C measured at 556uF
  • C45 = 10V 470uF 85C measured at 227uF, then 637uF then 600uF

I’ve ordered an analog board kit from https://console5.com/store/macintosh-128k-512k-plus-analog-pcb-cap-kit-630-0102-661-0462.html and when trying to put them in, I learned that the US Analog board is different to the International Analog board!!! Gah. Dammit.

Note that C30, C32, C38, C39, and C37 were missing from the kit I received (probably due to differences in the US and International boards). I did have an X2 cap (for C37) but it was 0.1uF not 0.47uF. I also had two extra 1000uF 16V caps.

Macintosh Repair and Upgrade Secrets (up to the Mac SE no less!) holds an Appendix with the parts listing for both the US and International Analog boards, and this led me to conclude that they are in fact different boards rather than just a few wires that are different. I am not sure what the “For 120V operation, W12 must be in place” and “for 240V operation, W12 must be removed” writing is about on the International Analog board, but I’m not quite up to messing with that at the moment.

So, I ordered the parts (linked above) and waited (again) to be able to finish re-capping the board.

I found https://youtu.be/H9dxJ7uNXOA video to be a good one for learning a bunch about the insides of compact Macs, I recommend it and several others on his YouTube channel. One interesting thing I learned is that the X2 cap (C37 on the International one) is before the power switch, so could blow just by having the system plugged in and not turned on! Okay, so I’m kind of assuming that it also applies to the International board, and mine exploded while it was plugged in and switched on, so YMMV.

Additionally, there’s an interesting list of commonly failing parts. Unfortunately, this is also for the US logic board, so the tables in Macintosh Repair and Upgrade Secrets are useful. I’m hoping that I don’t have to replace anything more there, but we’ll see.

But, after the Nth round of parts being delivered….

Note the lack of an exploded capacitor

Yep, that’s where the exploded cap was before. Cleanup up all pretty nicely actually. Annoyingly, I had to run it all through a step-up transformer as the board is all set for Australian 240V rather than US 120V. This isn’t going to be an everyday computer though, so it’s fine.

Macintosh Plus booting up (note how long the memory check of 4MB of RAM takes. I’m being very careful as the cover is off. High, and possibly lethal voltages exposed.

Woohoo! It works. While I haven’t found my supply of floppy disks that (at least used to) work, the floppy mechanism also seems to work okay.

Macintosh Plus with a seemingly working floppy drive mechanism. I haven’t found a boot floppy yet though.

Next up: waiting for my Floppy Emu to arrive as it’ll certainly let it boot. Also, it’s now time to rip the house apart to find a floppy disk that certainly should have made its way across the ocean with the move…. Oh, and also to clean up the mouse and keyboard.

My POWER9 CPU Core Layout

So, following on from my post on Sensors on the Blackbird (and thus Power9), I mentioned that when you look at the temperature sensors for each CPU core in my 8-core POWER9 chip, they’re not linear numbers. Let’s look at what that means….

stewart@blackbird9$ sudo ipmitool sensor | grep core
 p0_core0_temp            | na
 p0_core1_temp            | na
 p0_core2_temp            | na
 p0_core3_temp            | 38.000
 p0_core4_temp            | na
 p0_core5_temp            | 38.000
 p0_core6_temp            | na
 p0_core7_temp            | 38.000
 p0_core8_temp            | na
 p0_core9_temp            | na
 p0_core10_temp           | na
 p0_core11_temp           | 37.000
 p0_core12_temp           | na
 p0_core13_temp           | na
 p0_core14_temp           | na
 p0_core15_temp           | 37.000
 p0_core16_temp           | na
 p0_core17_temp           | 37.000
 p0_core18_temp           | na
 p0_core19_temp           | 39.000
 p0_core20_temp           | na
 p0_core21_temp           | 39.000
 p0_core22_temp           | na
 p0_core23_temp           | na

You can see I have eight CPU cores in my Blackbird system. The reason the 8 CPU cores are core 3, 5, 7, 11, 15, 17, 19, and 21 rather than 0-8 or something is that these represent the core numbers on the physical die, and the die is a 24 core die. When you’re making a chip as big and as complex as modern high performance CPUs, not all of the chips coming out of your fab are going to be perfect, so this is how you get different models in the line with only one production line.

Weirdly, the output from the hwmon sensors and why there’s a “core 24” and a “core 28”. That’s just… wrong. What it is, however, is right if you think of 8*4=32. This is a product of Linux thinking that Thread=Core in some ways. So, yeah, this numbering is the first thread of each logical core.

[stewart@blackbird9 ~]$ sensors|grep -i core
 Chip 0 Core 0:            +39.0°C  (lowest = +25.0°C, highest = +71.0°C)
 Chip 0 Core 4:            +39.0°C  (lowest = +26.0°C, highest = +66.0°C)
 Chip 0 Core 8:            +39.0°C  (lowest = +27.0°C, highest = +67.0°C)
 Chip 0 Core 12:           +39.0°C  (lowest = +26.0°C, highest = +67.0°C)
 Chip 0 Core 16:           +39.0°C  (lowest = +25.0°C, highest = +67.0°C)
 Chip 0 Core 20:           +39.0°C  (lowest = +26.0°C, highest = +69.0°C)
 Chip 0 Core 24:           +39.0°C  (lowest = +27.0°C, highest = +67.0°C)
 Chip 0 Core 28:           +39.0°C  (lowest = +27.0°C, highest = +64.0°C)

But let’s ignore that, go from the IPMI sensors (which also match what the OCC shows with “occtoolp9 -LS” (see below).

$ ./occtoolp9 -SL
Sensor Details: (found 86 sensors, details only for Status of 0x00)
     GUID Name             Sample     Min    Max U    Stat   Accum     UpdFreq   ScaleFactr   Loc   Type
....
   0x00ED TEMPC03………     47      29     47 C    0x00 0x00037CF2 0x00007D00 0x00000100 0x0040 0x0008
   0x00EF TEMPC05………     37      26     39 C    0x00 0x00014E53 0x00007D00 0x00000100 0x0040 0x0008
   0x00F1 TEMPC07………     46      28     46 C    0x00 0x0001A777 0x00007D00 0x00000100 0x0040 0x0008
   0x00F5 TEMPC11………     44      27     45 C    0x00 0x00018402 0x00007D00 0x00000100 0x0040 0x0008
   0x00F9 TEMPC15………     36      25     43 C    0x00 0x000183BC 0x00007D00 0x00000100 0x0040 0x0008
   0x00FB TEMPC17………     38      28     41 C    0x00 0x00015474 0x00007D00 0x00000100 0x0040 0x0008
   0x00FD TEMPC19………     43      27     44 C    0x00 0x00016589 0x00007D00 0x00000100 0x0040 0x0008
   0x00FF TEMPC21………     36      30     40 C    0x00 0x00015CA9 0x00007D00 0x00000100 0x0040 0x0008

So what does that mean for physical layout? Well, like all modern high performance chips, the POWER9 is modular, with a bunch of logic being replicated all over the die. The most notable duplicated parts are the core (replicated 24 times!) and cache structures. Less so are memory controllers and PCI hardware.

P9 chip layout from page 31 of the POWER9 Register Specification

See that each core (e.g. EC00 and EC01) is paired with the cache block (EC00 and EC01 with EP00). That’s two POWER9 cores with one 512KB L2 cache and one 10MB L3 cache.

You can see the cache layout (including L1 Instruction and Data caches) by looking in sysfs:

$ for i in /sys/devices/system/cpu/cpu0/cache/index*/; \
  do echo -n $(cat $i/level) $(cat $i/size) $(cat $i/type); \
  echo; done
 1 32K Data
 1 32K Instruction
 2 512K Unified
 3 10240K Unified

So, what does the layout of my POWER9 chip look like? Well, thanks to the power of graphics software, we can cross some cores out and look at the topology:

My 8-core POWER9 CPU in my Raptor Blackbird

If I run some memory bandwidth benchmarks, I can see that you can see the L3 cache capacity you’d assume from the above diagram: 80MB (10MB/core). Let’s see:

[stewart@blackbird9 lmbench3]$ for i in 5M 10M 20M 30M 40M 50M 60M 70M 80M 500M; \
  do echo -n "$i   "; \
  ./bin/bw_mem -N 100  $i rd; \
done
  5M    5.24 63971.98
 10M   10.49 31940.14
 20M   20.97 17620.16
 30M   31.46 18540.64
 40M   41.94 18831.06
 50M   52.43 17372.03
 60M   62.91 16072.18
 70M   73.40 14873.42
 80M   83.89 14150.82
 500M 524.29 14421.35

If all the cores were packed together, I’d expect that cliff to be a lot sooner.

So how does this compare to other machines I have around? Well, let’s look at my Ryzen 7. Specifically, a “AMD Ryzen 7 1700 Eight-Core Processor”. The cache layout is:

$ for i in /sys/devices/system/cpu/cpu0/cache/index*/; \
  do echo -n $(cat $i/level) $(cat $i/size) $(cat $i/type); \
  echo; \
done
 1 32K Data
 1 64K Instruction
 2 512K Unified
 3 8192K Unified

And then the performance benchmark similar to the one I ran above on the POWER9 (lower numbers down low as 8MB is less than 10MB)

$ for i in 4M 8M 16M 24M 32M 40M 48M 56M 64M 72M 80M 500M; \
  do echo -n "$i   "; ./bin/x86_64-linux-gnu/bw_mem -N 10  $i rd;\
done
  4M    4.19 61111.04
  8M    8.39 28596.55
 16M   16.78 21415.12
 24M   25.17 20153.57
 32M   33.55 20448.20
 40M   41.94 20940.11
 48M   50.33 20281.39
 56M   58.72 21600.24
 64M   67.11 21284.13
 72M   75.50 20596.18
 80M   83.89 20802.40
 500M 524.29 21489.27

And my laptop? It’s a four core part, specifically a “Intel(R) Core(TM) i5-10210U CPU @ 1.60GHz” with a cache layout like:

$ for i in /sys/devices/system/cpu/cpu0/cache/index*/; \
   do echo -n $(cat $i/level) $(cat $i/size) $(cat $i/type); \
     echo; \
   done
   1 32K Data
   1 32K Instruction
   2 256K Unified
   3 6144K Unified
$ for i in 3M 6M 12M 18M 24M 30M 36M 42M 500M; \
  do echo -n "$i   "; ./bin/x86_64-linux-gnu/bw_mem -N 10  $i rd;\
done
  3M    3.15 48500.24
  6M    6.29 27144.16
 12M   12.58 18731.80
 18M   18.87 17757.74
 24M   25.17 17154.12
 30M   31.46 17135.87
 36M   37.75 16899.75
 42M   44.04 16865.44
 500M 524.29 16817.10

I’m not sure what performance conclusions we can realistically draw from these curves, apart from “keeping workload to L3 cache is cool”, and “different chips have different cache hardware”, and “I should probably go and read and remember more about the microarchitectural characteristics of the cache hardware in Ryzen 7 hardware and 10th gen Intel Core hardware”.

OCC and Sensors on the Raptor Blackbird (and other POWER9 systems)

This post we’re going to look at three different ways to look at various sensors in the Raptor Blackbird system. The Blackbird is a single socket uATX board for the POWER9 processor. One advantage of the system is completely open source firmware, so you can (like I have): build your own firmware. So, this is my Blackbird running my most recent firmware build (the BMC is running the 2.00 release from Raptor).

Sensors over IPMI

One way to get the sensors is over IPMI. This can be done either in-band (as in, from the OS running on the blackbird), or over the network.

stewart@blackbird9$ sudo ipmitool sensor |head
occ                      | na         | discrete   | na    | na        | na        | na        | na        | na        | na
 occ0                     | 0x0        | discrete   | 0x0200| na        | na        | na        | na        | na        | na
 occ1                     | 0x0        | discrete   | 0x0100| na        | na        | na        | na        | na        | na
 p0_core0_temp            | na         |            | na    | na        | na        | na        | na        | na        | na
 p0_core1_temp            | na         |            | na    | na        | na        | na        | na        | na        | na
 p0_core2_temp            | na         |            | na    | na        | na        | na        | na        | na        | na
 p0_core3_temp            | 38.000     | degrees C  | ok    | na        | -40.000   | na        | 78.000    | 90.000    | na
 p0_core4_temp            | na         |            | na    | na        | na        | na        | na        | na        | na
 p0_core5_temp            | 38.000     | degrees C  | ok    | na        | -40.000   | na        | 78.000    | 90.000    | na
 p0_core6_temp            | na         |            | na    | na        | na        | na        | na        | na        | na

It’s kind of annoying to read there, so standard unix tools to the rescue!

stewart@blackbird9$ sudo ipmitool sensor | cut -d '|' -f 1,2
 occ                      | na
 occ0                     | 0x0
 occ1                     | 0x0
 p0_core0_temp            | na
 p0_core1_temp            | na
 p0_core2_temp            | na
 p0_core3_temp            | 38.000
 p0_core4_temp            | na
 p0_core5_temp            | 38.000
 p0_core6_temp            | na
 p0_core7_temp            | 38.000
 p0_core8_temp            | na
 p0_core9_temp            | na
 p0_core10_temp           | na
 p0_core11_temp           | 37.000
 p0_core12_temp           | na
 p0_core13_temp           | na
 p0_core14_temp           | na
 p0_core15_temp           | 37.000
 p0_core16_temp           | na
 p0_core17_temp           | 37.000
 p0_core18_temp           | na
 p0_core19_temp           | 39.000
 p0_core20_temp           | na
 p0_core21_temp           | 39.000
 p0_core22_temp           | na
 p0_core23_temp           | na
 p0_vdd_temp              | 40.000
 dimm0_temp               | 35.000
 dimm1_temp               | na
 dimm2_temp               | na
 dimm3_temp               | na
 dimm4_temp               | 38.000
 dimm5_temp               | na
 dimm6_temp               | na
 dimm7_temp               | na
 dimm8_temp               | na
 dimm9_temp               | na
 dimm10_temp              | na
 dimm11_temp              | na
 dimm12_temp              | na
 dimm13_temp              | na
 dimm14_temp              | na
 dimm15_temp              | na
 fan0                     | 1200.000
 fan1                     | 1100.000
 fan2                     | 1000.000
 p0_power                 | 33.000
 p0_vdd_power             | 5.000
 p0_vdn_power             | 9.000
 cpu_1_ambient            | 30.600
 pcie                     | 27.000
 ambient                  | 26.000

You can see that I have 3 fans, two DIMMs (although why it lists 16 possible DIMMs for a two DIMM slot board is a good question!), and eight CPU cores. More on why the layout of the CPU cores is the way it is in a future post.

The code path for reading these sensors is interesting, it’s all from the BMC, so we’re having the OCC inside the P9 read things, which the BMC then reads, and then passes back to the P9. On the P9 itself, each sensor is a call all the way to firmware and back! In fact, we can look at it in perf:

$ sudo perf record -g ipmitool sensor
$ sudo perf report --no-children
“ipmitool sensors” perf report

What are the 0x300xxxxx addresses? They’re the OPAL firmware (i.e. skiboot). We can look up the symbols easily, as the firmware exposes them to the kernel, which then plonks it in sysfs:

[stewart@blackbird9 ~]$ sudo head /sys/firmware/opal/symbol_map
[sudo] password for stewart:
0000000000000000 R __builtin_kernel_end
0000000000000000 R __builtin_kernel_start
0000000000000000 T __head
0000000000000000 T _start
0000000000000010 T fdt_entry
00000000000000f0 t boot_sem
00000000000000f4 t boot_flag
00000000000000f8 T attn_trigger
00000000000000fc T hir_trigger
0000000000000100 t sreset_vector

So we can easily look up exactly where this is:

[stewart@blackbird9 ~]$ sudo grep '18e.. ' /sys/firmware/opal/symbol_map
 0000000000018e20 t .__try_lock.isra.0
 0000000000018e68 t .add_lock_request

So we’re managing to spend a whole 12% of execution time spinning on a spinlock in firmware! The call stack of what’s going on in firmware isn’t so easy, but we can find the bt_add_ipmi_msg call there which is probably how everything starts:

[stewart@blackbird9 ~]$ sudo grep '516.. ' /sys/firmware/opal/symbol_map   0000000000051614 t .bt_add_ipmi_msg_head  0000000000051688 t .bt_add_ipmi_msg  00000000000516fc t .bt_poll

OCCTOOL

This is the most not-what-you’re-meant-to-use method of getting access to sensors! It’s using a debug tool for the OCC firmware! There’s a variety of tools in the OCC source repositiory, and one of them (occtoolp9) can be used for a variety of things, one of which is getting sensor data out of the OCC.

$ sudo ./occtoolp9 -SL
     Sensor Type: 0xFFFF
 Sensor Location: 0xFFFF
     (only displaying non-zero sensors)
 Sending 0x53 command to OCC0 (via opal-prd)…
   MFG Sub Cmd: 0x05  (List Sensors)
   Num Sensors: 50
     [ 1] GUID: 0x0000 / AMEintdur…….  Sample:     20  (0x0014)
     [ 2] GUID: 0x0001 / AMESSdur0…….  Sample:      7  (0x0007)
     [ 3] GUID: 0x0002 / AMESSdur1…….  Sample:      3  (0x0003)
     [ 4] GUID: 0x0003 / AMESSdur2…….  Sample:     23  (0x0017)

The odd thing you’ll see is “via opal-prd” – and this is because it’s doing raw calls to the opal-prd binary to talk to the OCC firmware running things like “opal-prd --expert-mode htmgt-passthru“. Yeah, this isn’t a in-production thing :)

Amazingly (and interestingly), this doesn’t go through host firmware in the way that an IPMI call will. There’s a full OCC/Host firmware interface spec to read. But it’s insanely inefficient way to monity sensors, a long bash script shelling out to a whole bunch of other processes… Think ~14.4 billion cycles versus ~367million cycles for the ipmitool option above.

But there are some interesting sensors at the end of the list:

Sensor Details: (found 86 sensors, details only for Status of 0x00)
     GUID Name             Sample     Min    Max U    Stat   Accum     UpdFreq   ScaleFactr   Loc   Type
....
   0x014A MRDM0………..    688       3  15015 GBs  0x00 0x0144AE6C 0x00001901 0x000080FB 0x0008 0x0200
   0x014E MRDM4………..    480       3  14739 GBs  0x00 0x01190930 0x00001901 0x000080FB 0x0008 0x0200
   0x0156 MWRM0………..    560       4  16605 GBs  0x00 0x014C61FD 0x00001901 0x000080FB 0x0008 0x0200
   0x015A MWRM4………..    360       4  16597 GBs  0x00 0x014AE231 0x00001901 0x000080FB 0x0008 0x0200

is that memory bandwidth? Well, if I run the STREAM benchmark in a loop and look again:

0x014A MRDM0………..  15165       3  17994 GBs  0x00 0x0C133D6C 0x00001901 0x000080FB 0x0008 0x0200
   0x014E MRDM4………..  17145       3  18016 GBs  0x00 0x0BF501D6 0x00001901 0x000080FB 0x0008 0x0200
   0x0156 MWRM0………..   8063       4  24280 GBs  0x00 0x07C98B88 0x00001901 0x000080FB 0x0008 0x0200
   0x015A MWRM4………..   1138       4  24215 GBs  0x00 0x07CE82AF 0x00001901 0x000080FB 0x0008 0x0200

It looks like it! Are these exposed elsewhere? Well, another blog post at some point in the future is where I should look at that.

lm-sensors

$ rpm -qf /usr/bin/sensors
 lm_sensors-3.5.0-6.fc31.ppc64le

Ahhh, old faithful lm-sensors! Yep, a whole bunch of sensors are just exposed over the standard interface that we’ve been using since ISA was a thing.

[stewart@blackbird9 ~]$ sensors
 ibmpowernv-isa-0000
 Adapter: ISA adapter
 Chip 0 Vdd Remote Sense:  +1.02 V  (lowest =  +0.72 V, highest =  +1.02 V)
 Chip 0 Vdn Remote Sense:  +0.67 V  (lowest =  +0.67 V, highest =  +0.67 V)
 Chip 0 Vdd:               +1.02 V  (lowest =  +0.73 V, highest =  +1.02 V)
 Chip 0 Vdn:               +0.68 V  (lowest =  +0.68 V, highest =  +0.68 V)
 Chip 0 Core 0:            +47.0°C  (lowest = +25.0°C, highest = +71.0°C)
 Chip 0 Core 4:            +47.0°C  (lowest = +26.0°C, highest = +66.0°C)
 Chip 0 Core 8:            +48.0°C  (lowest = +27.0°C, highest = +67.0°C)
 Chip 0 Core 12:           +48.0°C  (lowest = +26.0°C, highest = +67.0°C)
 Chip 0 Core 16:           +47.0°C  (lowest = +25.0°C, highest = +67.0°C)
 Chip 0 Core 20:           +47.0°C  (lowest = +26.0°C, highest = +69.0°C)
 Chip 0 Core 24:           +48.0°C  (lowest = +27.0°C, highest = +67.0°C)
 Chip 0 Core 28:           +51.0°C  (lowest = +27.0°C, highest = +64.0°C)
 Chip 0 DIMM 0 :           +40.0°C  (lowest = +34.0°C, highest = +44.0°C)
 Chip 0 DIMM 1 :            +0.0°C  (lowest =  +0.0°C, highest =  +0.0°C)
 Chip 0 DIMM 2 :            +0.0°C  (lowest =  +0.0°C, highest =  +0.0°C)
 Chip 0 DIMM 3 :            +0.0°C  (lowest =  +0.0°C, highest =  +0.0°C)
 Chip 0 DIMM 4 :            +0.0°C  (lowest =  +0.0°C, highest =  +0.0°C)
 Chip 0 DIMM 5 :            +0.0°C  (lowest =  +0.0°C, highest =  +0.0°C)
 Chip 0 DIMM 6 :            +0.0°C  (lowest =  +0.0°C, highest =  +0.0°C)
 Chip 0 DIMM 7 :            +0.0°C  (lowest =  +0.0°C, highest =  +0.0°C)
 Chip 0 DIMM 8 :            +0.0°C  (lowest =  +0.0°C, highest =  +0.0°C)
 Chip 0 DIMM 9 :            +0.0°C  (lowest =  +0.0°C, highest =  +0.0°C)
 Chip 0 DIMM 10 :           +0.0°C  (lowest =  +0.0°C, highest =  +0.0°C)
 Chip 0 DIMM 11 :           +0.0°C  (lowest =  +0.0°C, highest =  +0.0°C)
 Chip 0 DIMM 12 :          +43.0°C  (lowest = +36.0°C, highest = +47.0°C)
 Chip 0 DIMM 13 :           +0.0°C  (lowest =  +0.0°C, highest =  +0.0°C)
 Chip 0 DIMM 14 :           +0.0°C  (lowest =  +0.0°C, highest =  +0.0°C)
 Chip 0 DIMM 15 :           +0.0°C  (lowest =  +0.0°C, highest =  +0.0°C)
 Chip 0 Nest:              +48.0°C  (lowest = +27.0°C, highest = +64.0°C)
 Chip 0 VRM VDD:           +47.0°C  (lowest = +39.0°C, highest = +66.0°C)
 Chip 0 :                  44.00 W  (lowest =  31.00 W, highest = 132.00 W)
 Chip 0 Vdd:               15.00 W  (lowest =   4.00 W, highest = 104.00 W)
 Chip 0 Vdn:               10.00 W  (lowest =   8.00 W, highest =  12.00 W)
 Chip 0 :                 227.11 kJ
 Chip 0 Vdd:               44.80 kJ
 Chip 0 Vdn:               58.80 kJ
 Chip 0 Vdd:              +21.50 A  (lowest =  +6.50 A, highest = +104.75 A)
 Chip 0 Vdn:              +14.88 A  (lowest = +12.63 A, highest = +18.88 A)

The best thing? It’s really quick! The hwmon interface is fast and efficient.

Yet another near-upstream Raptor Blackbird firmware build

In what is coming a month occurance, I’ve put up yet another firmware build for the Raptor Blackbird with close-to-upstream firmware (see here and here for previous ones).

Well, I’ve done another build! It’s current op-build (as of yesterday), but my branch with patches for the Raptor Blackbird. The skiboot patch is there, the SBE speedup patch is now upstream. The machine-xml which is straight from Raptor but in my repo.

Here’s the current versions of everything:

$ lsprop /sys/firmware/devicetree/base/ibm,firmware-versions/
skiboot          "v6.5-228-g82aed17a-p4360f95"
bmc-firmware-version
                 "0.00"
occ              "3ab2921"
hostboot         "acdff8a-pe7e80e1"
buildroot        "2019.05.3-15-g3a4fc2a888"
capp-ucode       "p9-dd2-v4"
machine-xml      "site_local-stewart-a0efd66"
hostboot-binaries
                 "hw013120a.opmst"
sbe              "c318ab0-p1ddf83c"
hcode            "hw030220a.opmst"
petitboot        "v1.12"
phandle          0000064c (1612)
version          "blackbird-v2.4-514-g62d1a941"
linux            "5.4.22-openpower1-pdbbf8c8"
name             "ibm,firmware-versions"

If we compare this to the last build I put up, we have:

Componentoldnew
skibootv6.5-209-g179d53df-p4360f95v6.5-228-g82aed17a-p4360f95
linux5.4.13-openpower1-pa361bec5.4.22-openpower1-pdbbf8c8
occ3ab2921no change
hostboot779761d-pe7e80e1acdff8a-pe7e80e1
buildroot2019.05.3-14-g17f117295f2019.05.3-15-g3a4fc2a888
capp-ucodep9-dd2-v4no change
machine-xmlsite_local-stewart-a0efd66no change
hostboot-binarieshw011120a.opmsthw013120a.opmst
sbe166b70c-p06fc80cc318ab0-p1ddf83c
hcodehw011520a.opmsthw030220a.opmst
petitbootv1.11v1.12
versionblackbird-v2.4-415-gb63b36efblackbird-v2.4-514-g62d1a941

So, what do those changes mean? Not too much changed over the past month. Kernel bump, new petitboot (although I can’t find release notes but it doesn’t look like there’s a lot of changes), and slight bumps to other firmware components.

Grab blackbird.pnor from https://www.flamingspork.com/blackbird/stewart-blackbird-4-images/ and give it a whirl!

To flash it, copy blackbird.pnor to your Blackbird’s BMC in /tmp/ (important! the /tmp filesystem has enough room, the home directory for root does not), and then run:

pflash -E -p /tmp/blackbird.pnor

Which will ask you to confirm and then flash:

About to erase chip !
WARNING ! This will modify your HOST flash chip content !
Enter "yes" to confirm:yes
Erasing... (may take a while)
[==================================================] 99% ETA:1s
done !
About to program "/tmp/blackbird.pnor" at 0x00000000..0x04000000 !
Programming & Verifying...
[==================================================] 100% ETA:0s

Booting temporary firmware on the Raptor Blackbird

In a future post, I’ll detail how to build my ported-to-upstream Blackbird firmware. Here though, we’ll explore booting some firmware temporarily to experiment.

Step 1: Copy your new PNOR image over to the BMC.
Step 2: …
Step 3: Profit!

Okay, not really, once you’ve copied over your image, ensure the computer is off and then you can tell the daemon that provides firmware to the host to use a file backend for it rather than the PNOR chip on the motherboard (i.e. yes, you can boot your system even when the firmware chip isn’t there – although I’ve not literally tried this).

root@blackbird:~# mboxctl --backend file:/tmp/blackbird.pnor
SetBackend: Success
root@blackbird:~# obmcutil poweron

If we look at the serial console (ssh to the BMC port 2200) we’ll see Hostboot start, realise there’s newer SBE code, flash it, and reboot:

--== Welcome to Hostboot hostboot-b284071/hbicore.bin ==--

  3.02606|secure|SecureROM valid - enabling functionality
  5.14678|Booting from SBE side 0 on master proc=00050000
  5.18537|ISTEP  6. 5 - host_init_fsi
  5.47985|ISTEP  6. 6 - host_set_ipl_parms
  5.54476|ISTEP  6. 7 - host_discover_targets
  6.56106|HWAS|PRESENT> DIMM[03]=8080000000000000
  6.56108|HWAS|PRESENT> Proc[05]=8000000000000000
  6.56109|HWAS|PRESENT> Core[07]=1511540000000000
  6.61373|ISTEP  6. 8 - host_update_master_tpm
  6.61529|SECURE|Security Access Bit> 0x0000000000000000
  6.61530|SECURE|Secure Mode Disable (via Jumper)> 0x8000000000000000
  6.61543|ISTEP  6. 9 - host_gard
  7.20987|HWAS|FUNCTIONAL> DIMM[03]=8080000000000000
  7.20988|HWAS|FUNCTIONAL> Proc[05]=8000000000000000
  7.20989|HWAS|FUNCTIONAL> Core[07]=1511540000000000
  7.21299|ISTEP  6.11 - host_start_occ_xstop_handler
  8.28965|ISTEP  6.12 - host_voltage_config
  8.47973|ISTEP  7. 1 - mss_attr_cleanup
  9.07674|ISTEP  7. 2 - mss_volt
  9.35627|ISTEP  7. 3 - mss_freq
  9.63029|ISTEP  7. 4 - mss_eff_config
 10.35189|ISTEP  7. 5 - mss_attr_update
 10.38489|ISTEP  8. 1 - host_slave_sbe_config
 10.45332|ISTEP  8. 2 - host_setup_sbe
 10.45450|ISTEP  8. 3 - host_cbs_start
 10.45574|ISTEP  8. 4 - proc_check_slave_sbe_seeprom_complete
 10.48675|ISTEP  8. 5 - host_attnlisten_proc
 10.50338|ISTEP  8. 6 - host_p9_fbc_eff_config
 10.50771|ISTEP  8. 7 - host_p9_eff_config_links
 10.53338|ISTEP  8. 8 - proc_attr_update
 10.53634|ISTEP  8. 9 - proc_chiplet_fabric_scominit
 10.55234|ISTEP  8.10 - proc_xbus_scominit
 10.56202|ISTEP  8.11 - proc_xbus_enable_ridi
 10.57788|ISTEP  8.12 - host_set_voltages
 10.59421|ISTEP  9. 1 - fabric_erepair
 10.65877|ISTEP  9. 2 - fabric_io_dccal
 10.66048|ISTEP  9. 3 - fabric_pre_trainadv
 10.66665|ISTEP  9. 4 - fabric_io_run_training
 10.66860|ISTEP  9. 5 - fabric_post_trainadv
 10.67060|ISTEP  9. 6 - proc_smp_link_layer
 10.67503|ISTEP  9. 7 - proc_fab_iovalid
 11.10386|ISTEP  9. 8 - host_fbc_eff_config_aggregate
 11.15103|ISTEP 10. 1 - proc_build_smp
 11.27537|ISTEP 10. 2 - host_slave_sbe_update
 11.68581|sbe|System Performing SBE Update for PROC 0, side 0
 34.50467|sbe|System Rebooting To Complete SBE Update Process
 34.50595|IPMI: Initiate power cycle
 34.54671|Stopping istep dispatcher
 34.68729|IPMI: shutdown complete

One of the improvements is we now get output from the SBE! This means that when we do things like mess up secure boot and non secure boot firmware (I’ll explain why/how this is a thing later), we’ll actually get something useful out of a serial port:

--== Welcome to SBE - CommitId[0x8b06b5c1] ==--
istep 3.19
istep 3.20
istep 3.21
istep 3.22
istep 4.1
istep 4.2
istep 4.3
istep 4.4
istep 4.5
istep 4.6
istep 4.7
istep 4.8
istep 4.9
istep 4.10
istep 4.11
istep 4.12
istep 4.13
istep 4.14
istep 4.15
istep 4.16
istep 4.17
istep 4.18
istep 4.19
istep 4.20
istep 4.21
istep 4.22
istep 4.23
istep 4.24
istep 4.25
istep 4.26
istep 4.27
istep 4.28
istep 4.29
istep 4.30
istep 4.31
istep 4.32
istep 4.33
istep 4.34
istep 5.1
istep 5.2
SBE starting hostboot

And then we’re back into normal Hostboot boot (which we’ve all seen before) and end up at a newer petitboot!

Petitboot 1.11 on a Raptor Blackbird

One notable absence from that screenshot is my installed Fedora is missing. This is because there appears to be a bug in the 5.3.7 kernel that’s currently upstream, and if we drop to the shell and poke at lspci and dmesg, we can work out what could be the culprit:

Exiting petitboot. Type 'exit' to return.
You may run 'pb-sos' to gather diagnostic data
No password set, running as root. You may set a password in the System Configuration screen.
# lspci
0000:00:00.0 PCI bridge: IBM Device 04c1
0001:00:00.0 PCI bridge: IBM Device 04c1
0001:01:00.0 Non-Volatile memory controller: Intel Corporation Device f1a8 (rev 03)
0002:00:00.0 PCI bridge: IBM Device 04c1
0002:01:00.0 SATA controller: Marvell Technology Group Ltd. 88SE9235 PCIe 2.0 x2 4-port SATA 6 Gb/s Controller (rev 11)
0003:00:00.0 PCI bridge: IBM Device 04c1
0003:01:00.0 USB controller: Texas Instruments TUSB73x0 SuperSpeed USB 3.0 xHCI Host Controller (rev 02)
0004:00:00.0 PCI bridge: IBM Device 04c1
0004:01:00.0 Ethernet controller: Broadcom Limited NetXtreme BCM5719 Gigabit Ethernet PCIe (rev 01)
0004:01:00.1 Ethernet controller: Broadcom Limited NetXtreme BCM5719 Gigabit Ethernet PCIe (rev 01)
0004:01:00.2 Ethernet controller: Broadcom Limited NetXtreme BCM5719 Gigabit Ethernet PCIe (rev 01)
0005:00:00.0 PCI bridge: IBM Device 04c1
0005:01:00.0 PCI bridge: ASPEED Technology, Inc. AST1150 PCI-to-PCI Bridge (rev 04)
0005:02:00.0 VGA compatible controller: ASPEED Technology, Inc. ASPEED Graphics Family (rev 41)
# dmesg|grep -i nvme
[    2.991038] nvme nvme0: pci function 0001:01:00.0
[    2.991088] nvme 0001:01:00.0: enabling device (0140 -> 0142)
[    3.121799] nvme nvme0: Identify Controller failed (19)
[    3.121802] nvme nvme0: Removing after probe failure status: -5
# uname -a
Linux skiroot 5.3.7-openpower1 #2 SMP Sat Dec 14 09:06:20 PST 2019 ppc64le GNU/Linux

If for some reason the device didn’t show up in lspci, then I’d look at the skiboot firmware log, which is /sys/firmware/opal/msglog.

Looking at upstream stable kernel patches, it seems like 5.3.8 has a interesting looking patch when you realize that ppc64le uses a 64k page size:

commit efac0f186ea654e8389f5017c7f643ef48cb4b93
Author: Kevin Hao <haokexin@gmail.com>
Date:   Fri Oct 18 10:53:14 2019 +0800

    nvme-pci: Set the prp2 correctly when using more than 4k page

    commit a4f40484e7f1dff56bb9f286cc59ffa36e0259eb upstream.

    In the current code, the nvme is using a fixed 4k PRP entry size,
    but if the kernel use a page size which is more than 4k, we should
    consider the situation that the bv_offset may be larger than the
    dev->ctrl.page_size. Otherwise we may miss setting the prp2 and then
    cause the command can't be executed correctly.

    Fixes: dff824b2aadb ("nvme-pci: optimize mapping of small single segment requests")
    Cc: stable@vger.kernel.org
    Reviewed-by: Christoph Hellwig <hch@lst.de>
    Signed-off-by: Kevin Hao <haokexin@gmail.com>
    Signed-off-by: Keith Busch <kbusch@kernel.org>
    Signed-off-by: Greg Kroah-Hartman <gregkh@linuxfoundation.org>

So, time to go try 5.3.8. My yaks are getting quite smooth.

Oh, and when you’re done with your temporary firmware, either fiddle with mboxctl or restart the systemd service for it, or reboot your BMC or… well, I gotta leave you something to work out on your own :)

Building OpenPOWER firmware on Fedora 31

One of the challenges with Fedora 31 is that /usr/bin/python is now Python 3 rather than Python 2. Just about every python script in existence relies on /usr/bin/python being Python 2 and not anything else. I can’t really recall, but this probably happened with the 1.5 to 2 transition as well (although IIRC that was less breaking).

What this means is that for projects that are half-way through converting to python 3, everything breaks.

op-build is one of these projects.

So, we need:

After all that, you can actually build a pnor image on Fedora 31. Even on Fedora 31 ppc64le, which is literally what I’ve just done.

Blackbird (singing in the dead of night..)

Way back when Raptor Computer Systems was doing pre-orders for the microATX Blackboard POWER9 system, I put in a pre-order. Since then, I’ve had a few life changes (such as moving to the US and starting to work for Amazon rather than IBM), but I’ve finally gone and done (most of) the setup for my own POWER9 system on (or under) my desk.

An 8 core POWER9 CPU, in bubble wrap and plastic packaging.

Everything came in a big brown box, all rather well packed. I had the board, CPU, heatsink assembly and the special tool to attach the heatsink to the board. Although unique to POWER9, the heatsink/fan assembly was one of the easier ones I’ve ever attached to a board.

The board itself looks pretty much as you’d expect – there’s a big spot for the CPU, a couple of PCI slots, a couple of DIMM slots and some SATA connectors.

The bits that are a bit unusual for a micro-ATX board are the big space reserved for FlexVer, the ASPEED BMC chip and the socketed flash. FlexVer is something I’m not ever going to use, and instead wish that there was an on-board m2 SSD slot instead, even if it was just PCIe. Having to sacrifice a PCIe slot just for a SSD is kind of a bummer.

The Blackbird POWER9 board
The POWER9 chip in socket

One annoying thing is my DIMMs are taking their sweet time in getting here, so I couldn’t actually populate the board with any memory.

Even without memory though, you can start powering it on and see that everything else works okay (i.e. it’s not completely boned). So, even without DIMMs, I could plug it in, and observe the Hostboot firmware complaining about insufficient hardware to IPL the box.

It Lives!

Yep, out the console (via ssh) you clearly see where things fail:

--== Welcome to Hostboot hostboot-3beba24/hbicore.bin ==--

  3.03104|secure|SecureROM valid - enabling functionality
  6.67619|Booting from SBE side 0 on master proc=00050000
  6.85100|ISTEP  6. 5 - host_init_fsi
  7.23753|ISTEP  6. 6 - host_set_ipl_parms
  7.71759|ISTEP  6. 7 - host_discover_targets
 11.34738|HWAS|PRESENT> Proc[05]=8000000000000000
 11.34739|HWAS|PRESENT> Core[07]=1511540000000000
 11.69077|ISTEP  6. 8 - host_update_master_tpm
 11.73787|SECURE|Security Access Bit> 0x0000000000000000
 11.73787|SECURE|Secure Mode Disable (via Jumper)> 0x8000000000000000
 11.76276|ISTEP  6. 9 - host_gard
 11.96654|HWAS|FUNCTIONAL> Proc[05]=8000000000000000
 11.96655|HWAS|FUNCTIONAL> Core[07]=1511540000000000
 12.07554|================================================
 12.07554|Error reported by hwas (0x0C00) PLID 0x90000007
 12.10289|  checkMinimumHardware found no functional dimm cards.
 12.10290|  ModuleId   0x03 MOD_CHECK_MIN_HW
 12.10291|  ReasonCode 0x0c06 RC_SYSAVAIL_NO_MEMORY_FUNC
 12.10292|  UserData1  HUID of node : 0x0002000000000000
 12.10293|  UserData2  number of present, non-functional dimms : 0x0000000000000000
 12.10294|------------------------------------------------
 12.10417|  Callout type             : Procedure Callout
 12.10417|  Procedure                : EPUB_PRC_FIND_DECONFIGURED_PART
 12.10418|  Priority                 : SRCI_PRIORITY_HIGH
 12.10419|------------------------------------------------
 12.10420|  Hostboot Build ID: hostboot-3beba24/hbicore.bin
 12.10421|================================================
 12.51718|================================================
 12.51719|Error reported by hwas (0x0C00) PLID 0x90000007
 12.51720|  Insufficient hardware to continue.
 12.51721|  ModuleId   0x03 MOD_CHECK_MIN_HW
 12.51722|  ReasonCode 0x0c04 RC_SYSAVAIL_INSUFFICIENT_HW
 12.54457|  UserData1   : 0x0000000000000000
 12.54458|  UserData2   : 0x0000000000000000
 12.54458|------------------------------------------------
 12.54459|  Callout type             : Procedure Callout
 12.54460|  Procedure                : EPUB_PRC_FIND_DECONFIGURED_PART
 12.54461|  Priority                 : SRCI_PRIORITY_HIGH
 12.54462|------------------------------------------------
 12.54462|  Hostboot Build ID: hostboot-3beba24/hbicore.bin
 12.54463|================================================
 12.73660|System shutting down with error status 0x90000007
 12.75545|================================================
 12.75546|Error reported by istep (0x1700) PLID 0x90000007
 12.77991|  IStep failed, see other log(s) with the same PLID for reason.
 12.77992|  ModuleId   0x01 MOD_REPORTING_ERROR
 12.77993|  ReasonCode 0x1703 RC_FAILURE
 12.77994|  UserData1  eid of first error : 0x9000000800000c04
 12.77995|  UserData2  Reason code of first error : 0x0000000100000609
 12.77996|------------------------------------------------
 12.77996|  host_gard
 12.77997|------------------------------------------------
 12.77998|  Callout type             : Procedure Callout
 12.77998|  Procedure                : EPUB_PRC_HB_CODE
 12.77999|  Priority                 : SRCI_PRIORITY_LOW
 12.78000|------------------------------------------------
 12.78001|  Hostboot Build ID: hostboot-3beba24/hbicore.bin
 12.78002|================================================

Looking forward to getting some DIMMs to show/share more.

AWS Welcomes Stewart

A little over a month ago now, I started a new role at Amazon Web Services (AWS) as a Principal Engineer with Amazon Linux. Everyone has been wonderfully welcoming and helpful. I’m excited about the future here, the team, and our mission.

Thanks to all my IBM colleagues over the past five and a half and a bit years too, I really enjoyed working with you on OpenPOWER and hope it continues to gain traction. I have my Blackbird now and am eagerly waiting for a spare 20 minutes to assemble it.

CVE-2019-6260: Gaining control of BMC from the host processor

This is details for CVE-2019-6260 – which has been nicknamed “pantsdown” due to the nature of feeling that we feel that we’ve “caught chunks of the industry with their…” and combined with the fact that naming things is hard, so if you pick a bad name somebody would have to come up with a better one before we publish.

I expect OpenBMC to have a statement shortly.

The ASPEED ast2400 and ast2500 Baseboard Management Controller (BMC) hardware and firmware implement Advanced High-performance Bus (AHB) bridges, which allow arbitrary read and write access to the BMC’s physical address space from the host, or from the network if the BMC console uart is attached to a serial concentrator (this is atypical for most systems).

Common configuration of the ASPEED BMC SoC’s hardware features leaves it open to “remote” unauthenticated compromise from the host and from the BMC console. This stems from AHB bridges on the LPC and PCIe buses, another on the BMC console UART (hardware password protected), and the ability of the X-DMA engine to address all of the BMC’s M-Bus (memory bus).

This affects multiple BMC firmware stacks, including OpenBMC, AMI’s BMC, and SuperMicro. It is independent of host processor architecture, and has been observed on systems with x86_64 processors IBM POWER processors (there is no reason to suggest that other architectures wouldn’t be affected, these are just the ones we’ve been able to get access to)

The LPC, PCIe and UART AHB bridges are all explicitly features of Aspeed’s designs: They exist to recover the BMC during firmware development or to allow the host to drive the BMC hardware if the BMC has no firmware of its own. See section 1.9 of the AST2500 Software Programming Guide.

The typical consequence of external, unauthenticated, arbitrary AHB access is that the BMC fails to ensure all three of confidentiality, integrity and availability for its data and services. For instance it is possible to:

  1. Reflash or dump the firmware of a running BMC from the host
  2. Perform arbitrary reads and writes to BMC RAM
  3. Configure an in-band BMC console from the host
  4. “Brick” the BMC by disabling the CPU clock until the next AC power cycle

Using 1 we can obviously implant any malicious code we like, with the impact of BMC downtime while the flashing and reboot take place. This may take the form of minor, malicious modifications to the officially provisioned BMC image, as we can extract, modify, then repackage the image to be re-flashed on the BMC. As the BMC potentially has no secure boot facility it is likely difficult to detect such actions.

Abusing 3 may require valid login credentials, but combining 1 and 2 we can simply change the locks on the BMC by replacing all instances of the root shadow password hash in RAM with a chosen password hash – one instance of the hash is in the page cache, and from that point forward any login process will authenticate with the chosen password.

We obtain the current root password hash by using 1 to dump the current flash content, then using https://github.com/ReFirmLabs/binwalk to extract the rootfs, then simply loop-mount the rootfs to access /etc/shadow. At least one BMC stack doesn’t require this, and instead offers “Press enter for console”.

IBM has internally developed a proof-of-concept application that we intend to open-source, likely as part of the OpenBMC project, that demonstrates how to use the interfaces and probes for their availability. The intent is that it be added to platform firmware test
suites as a platform security test case. The application requires root user privilege on the host system for the LPC and PCIe bridges, or normal user privilege on a remote system to exploit the debug UART interface. Access from userspace demonstrates the vulnerability of systems in bare-metal cloud hosting lease arrangements where the BMC
is likely in a separate security domain to the host.

OpenBMC Versions affected: Up to at least 2.6, all supported Aspeed-based platforms

It only affects systems using the ASPEED ast2400, ast2500 SoCs. There has not been any investigation into other hardware.

The specific issues are listed below, along with some judgement calls on their risk.

iLPC2AHB bridge Pt I

State: Enabled at cold start
Description: A SuperIO device is exposed that provides access to the BMC’s address-space
Impact: Arbitrary reads and writes to the BMC address-space
Risk: High – known vulnerability and explicitly used as a feature in some platform designs
Mitigation: Can be disabled by configuring a bit in the BMC’s LPC controller, however see Pt II.

iLPC2AHB bridge Pt II

State: Enabled at cold start
Description: The bit disabling the iLPC2AHB bridge only removes write access – reads are still possible.
Impact: Arbitrary reads of the BMC address-space
Risk: High – we expect the capability and mitigation are not well known, and the mitigation has side-effects
Mitigation: Disable SuperIO decoding on the LPC bus (0x2E/0x4E decode). Decoding is controlled via hardware strapping and can be turned off at runtime, however disabling SuperIO decoding also removes the host’s ability to configure SUARTs, System wakeups, GPIOs and the BMC/Host mailbox

PCIe VGA P2A bridge

State: Enabled at cold start
Description: The VGA graphics device provides a host-controllable window mapping onto the BMC address-space
Impact: Arbitrary reads and writes to the BMC address-space
Risk: Medium – the capability is known to some platform integrators and may be disabled in some firmware stacks
Mitigation: Can be disabled or filter writes to coarse-grained regions of the AHB by configuring bits in the System Control Unit

DMA from/to arbitrary BMC memory via X-DMA

State: Enabled at cold start
Description: X-DMA available from VGA and BMC PCI devices
Impact: Misconfiguration can expose the entirety of the BMC’s RAM to the host
AST2400 Risk: High – SDK u-boot does not constrain X-DMA to VGA reserved memory
AST2500 Risk: Low – SDK u-boot restricts X-DMA to VGA reserved memory
Mitigation: X-DMA accesses are configured to remap into VGA reserved memory in u-boot

UART-based SoC Debug interface

State: Enabled at cold start
Description: Pasting a magic password over the configured UART exposes a hardware-provided debug shell. The capability is only exposed on one of UART1 or UART5, and interactions are only possible via the physical IO port (cannot be accessed from the host)
Impact: Misconfiguration can expose the BMC’s address-space to the network if the BMC console is made available via a serial concentrator.
Risk: Low
Mitigation: Can be disabled by configuring a bit in the System Control Unit

LPC2AHB bridge

State: Disabled at cold start
Description: Maps LPC Firmware cycles onto the BMC’s address-space
Impact: Misconfiguration can expose vulnerable parts of the BMC’s address-space to the host
Risk: Low – requires reasonable effort to configure and enable.
Mitigation: Don’t enable the feature if not required.
Note: As a counter-point, this feature is used legitimately on OpenPOWER systems to expose the boot flash device content to the host

PCIe BMC P2A bridge

State: Disabled at cold start
Description: PCI-to-BMC address-space bridge allowing memory and IO accesses
Impact: Enabling the device provides limited access to BMC address-space
Risk: Low – requires some effort to enable, constrained to specific parts of the BMC address space
Mitigation: Don’t enable the feature if not required.

Watchdog setup

State: Required system function, always available
Description: Misconfiguring the watchdog to use “System Reset” mode for BMC reboot will re-open all the “enabled at cold start” backdoors until the firmware reconfigures the hardware otherwise. Rebooting the BMC is generally possible from the host via IPMI “mc reset” command, and this may provide a window of opportunity for BMC compromise.
Impact: May allow arbitrary access to BMC address space via any of the above mechanisms
Risk: Low – “System Reset” mode is unlikely to be used for reboot due to obvious side-effects
Mitigation: Ensure BMC reboots always use “SOC Reset” mode

The CVSS score for these vulnerabilities is: https://nvd.nist.gov/vuln-metrics/cvss/v3-calculator?vector=3DAV:A/AC:L/PR:=N/UI:N/S:U/C:H/I:H/A:H/E:F/RL:U/RC:C/CR:H/IR:H/AR:M/MAV:L/MAC:L/MPR:N/MUI:N=/MS:U/MC:H/MI:H/MA:H

There is some debate on if this is a local or remote vulnerability, and it depends on if you consider the connection between the BMC and the host processor as a network or not.

The fix is platform dependent as it can involve patching both the BMC firmware and the host firmware.

For example, we have mitigated these vulnerabilities for OpenPOWER systems, both on the host and BMC side. OpenBMC has a u-boot patch that disables the features:

https://gerrit.openbmc-project.xyz/#/c/openbmc/meta-phosphor/+/13290/

Which platforms can opt into in the following way:

https://gerrit.openbmc-project.xyz/#/c/openbmc/meta-ibm/+/17146/

The process is opt-in for OpenBMC platforms because platform maintainers have the knowledge of if their platform uses affected hardware features. This is important when disabling the iLPC2AHB bridge as it can be a bit of a finicky process.

See also https://gerrit.openbmc-project.xyz/c/openbmc/docs/+/11164 for a WIP OpenBMC Security Architecture document which should eventually contain all these details.

For OpenPOWER systems, the host firmware patches are contained in op-build v2.0.11 and enabled for certain platforms. Again, this is not by default for all platforms as there is BMC work required as well as per-platform changes.

Credit for finding these problems: Andrew Jeffery, Benjamin
Herrenschmidt, Jeremy Kerr, Russell Currey, Stewart Smith. There have been many more people who have helped with this issue, and they too deserve thanks.

Switching to iPhone Part 2: Seriously?

In which I ask of Apple, “Seriously?”.

That was pretty much my reaction with Apple sticking to Lightning connectors rather than going with the USB-C standard. Having USB-C around the place for my last two (Android) phones was fantastic. I could charge a phone, external battery, a (future) laptop, all off the same wall wart and with the same cable. It is with some hilarity that I read that the new iPad Pro has USB-C rather than Lightning.

But Apple’s dongle fetish reigns supreme, and so I get a multitude of damn dongles all for a wonderfully inflated price with an Australia Tax whacked on top.

The most egregious one is the Lightning-to-3.5mm dongle. In the office, I have a good set of headphones. The idea is to block out the sound of an open plan office so I can actually get some concentrating done. With tiny dedicated MP3 players and my previous phones, these sounded great. The Apple dongle? It sounds terrible. Absolutely terrible. The Lighting-to-3.5mm adapter might be okay for small earbuds but it is nearly completely intolerable for any decent set of headphones. I’m now in the market for a Bluetooth headphone amplifier. Another bunch of money to throw at another damn dongle.

Luckily, there seems to be a really good Bluetooth headphone amplifier on Amazon. The same Amazon that no longer ships to Australia. Well, there’s an Australian seller, for six times the price.

Urgh.

Switching to iPhone: Part 1

I have used Android phones since the first one: the G1. I’m one of the (relatively) few people who has used Android 1.0. I’ve had numerous Android phones since then, mostly the Google flagship.

I have fond memories of the Nexus One and Galaxy Nexus, as well as a bunch of time running Cyanogen (often daily builds, because YOLO) to get more privacy preserving features (or a more recent Android). I had a Sony Z1 Compact for a while which was great bang for buck except for the fact the screen broke whenever you looked at it sideways. Great kudos to the Sony team for being so friendly to custom firmware loads.

I buy my hardware from physical stores. Why? Well, it means that the NSA and others get to spend extra effort to insert hardware modifications (backdoors), as well as the benefit of having a place to go to/set the ACCC on to get my rights under Australian Consumer Law.

My phone before last was a Nexus 5X. There were a lot of good things about this phone; the promise of fast charging via USB-C was one, as was the ever improving performance of the hardware and Android itself. Well… it just got progressively slower, and slower, and slower – as if it was designed to get near unusable by the time of the next Google phone announcement.

Inevitably, my 5X succumbed to the manufacturing defect that resulted in a boot loop. It would start booting, and then spontaneously reboot, in a loop, forever. The remedy? Replace it under warranty! That would take weeks, which isn’t a suitable timeframe in this day and age to be without a phone, so I mulled over buying a Google Pixel or my first ever iPhone (my iPhone owning friends assured me that if such a thing happens with an iPhone that Apple would have swapped it on the spot). Not wanting to give up a lot of the personal freedom that comes with the Android world, I spent the $100 more to get the Pixel, acutely aware that having a phone was now a near $1000/year habit.

The Google Pixel was a fantastic phone (except the price, they should have matched the iPhone price). The camera was the first phone camera I actually went “wow, I’m impressed” over. The eye-watering $279 to replace a cracked screen, the still eye-watering cost of USB-C cables, and the seat to process the HDR photos were all forgiven. It was a good phone. Until, that is, less than a year in, the battery was completely shot. It would power off when less than 40% and couldn’t last the trip from Melbourne airport to Melbourne city.

So, with a flagship phone well within the “reasonable quality” time that consumer law would dictate, I contacted Google after going through all the standard troubleshooting. Google agreed this was not normal and that the phone was defective. I was told that they would mail me a replacement, I could transfer my stuff over and then mail in the broken one. FANTASTIC!! This was soooo much better than the experience with the 5X.

Except that it wasn’t. A week later, I rang back to ask what was going on as I hadn’t received the replacement; it turns out Google had lied to me, I’d have to mail the phone to them and then another ten business days later I’d have a replacement. Errr…. no, I’ve been here before.

I rang the retailer, JB Hi-Fi; they said it would take them at least three weeks, which I told them was not acceptable nor a “reasonable timeframe” as dictated by consumer law.

So, with a bunch of travel imminent, I bought a big external USB-C battery and kept it constantly connected as without it the battery percentage went down faster than the minutes ticked over. I could sort it out once I was back from travel.

So, I’m back. In fact, I drove back from a weekend away and finally bit the bullet – I went to pick up a phone who’s manufacturer has a reputation of supporting their hardware.

I picked up an iPhone.

I figured I should write up how, why, my reasons, and experiences in switching phone platforms. I think my next post will be “Why iPhone and not a different Android”.

pwnm-sync: Synchronizing Patchwork and Notmuch

One of the core bits of infrastructure I use as a maintainer is Patchwork (I wrote about making it faster recently). Patchwork tracks patches sent to a mailing list, allowing me as a maintainer to track the state of them (New|Under Review|Changes Requested|Accepted etc), combine them into patch bundles, look at specific series, test results etc.

One of the core bits of software I use is my email client, notmuch. Most other mail clients are laughably slow and clunky, or just plain annoying for absorbing a torrent of mail and being able to deal with it or just plain ignore it but have it searchable locally.

You may think your mail client is better than notmuch, but you’re wrong.

A key feature of notmuch is tagging email. It doesn’t do the traditional “folders” but instead does tags (if you’ve used gmail, you’d be somewhat familiar).

One of my key work flows as a maintainer is looking at what patches are outstanding for a project, and then reviewing them. This should also be a core part of any contributor to a project too. You may think that a tag:unread and to:project-list@foo query would be enough, but that doesn’t correspond with what’s in patchwork.

So, I decided to make a tool that would add tags to messages in notmuch corresponding with the state of the patch in patchwork. This way, I could easily search for “patches marked as New in patchwork” (or Under Review or whatever) and see what I should be reviewing and looking at merging or commenting on.

Logically, this wouldn’t be that hard, just use the (new) Patchwork REST API to get the state of everything and issue the appropriate notmuch commands.

But just going one way isn’t that interesting, I wanted to be able to change the tags in notmuch and have them sync back up to Patchwork. So, I made that part of the tool too.

Introducing pwnm-sync: a tool to sync patchwork and notmuch.

notmuch-hello tag counts for pwnm-sync tagged
patches in patchwork
notmuch-hello tag counts for pwnm-sync tagged
patches in patchwork

With this tool I can easily see the patchwork state of any patch that I have in my notmuch database. For projects that I’m a maintainer on (i.e. can change the state of patches), If I update the patches of that email and run pwnm-sync again, it’ll update the state in patchwork.

I’ve been using this for a few weeks myself and it’s made my maintainer workflow significantly nicer.

It may also be useful to people who want to find what patches need some review.

The sync time is mostly dependent on how fast your patchwork instance is for API requests. Unfortunately, we need to make some improvements on the Patchwork side of things here, but a full sync of the above takes about 4 minutes for me. You can also add a –epoch option (with a date/time) to say “only fetch things from patchwork since that date” which makes things a lot quicker for incremental syncs. For me, I typically run it with an epoch of a couple of months ago, and that takes ~20-30 seconds to run. In this case, if you’ve locally updated a old patch, it will still sync that change up to patchwork.

Implementation Details

It’s a python3 script using the notmuch python bindings, the requests-futures module for asynchronous HTTP requests (so we can have the patchwork server assemble the next page of results while we process the previous one), and a local sqlite3 database to store state in so we can work out what changed locally / server side.

Getting it

Head to https://github.com/stewartsmith/pwnm-sync or just:

git clone https://github.com/stewartsmith/pwnm-sync.git

ccache and op-build

You may have heard of ccache (Compiler Cache) which saves you heaps of real world time when rebuilding a source tree that is rather similar to one you’ve recently built before. It’s really useful in buildroot based projects where you’re building similar trees, or have done a minor bump of some components.

In trying to find a commit which introduced a bug in op-build (OpenPOWER firmware), I noticed that hostboot wasn’t being built using ccache and we were always doing a full build. So, I started digging into it.

It turns out that a bunch of the perl scripts for parsing the Machine Readable Workbook XML in hostboot did a bunch of things like foreach $key (%hash) – which means that the code iterates over the items in hash order rather than an order that would produce predictable output such as “attribute name” or something. So… much messing with that later, I had hostboot generating the same output for the same input on every build.

Next step was to work out why I was still getting a lot of CCACHE misses. It turns out the default ccache size is 5GB. A full hostboot build uses around 7.1GB of that.

So, if building op-build with CCACHE, be sure to set both BR2_CCACHE=y in your config as well as something like BR2_CCACHE_INITIAL_SETUP="--max-size 20G"

Hopefully my patches hit hostboot and op-build soon.

How I do email (at home)

I thought I might write something up on how I’ve been doing email both at home and at work. I very much on purpose keep the two completely separate, and have slightly different use cases for both of them.

For work, I do not want mail on my phone. For personal mail, it turns out I do want this on my phone, which is currently an Android phone. Since my work and personal email is very separate, the volume of mail is really, really different. Personal mail is maybe a couple of dozen a day at most. Work is… orders of magnitude more.

Considering I generally prefer free software to non-free software, K9 Mail is the way I go on my phone. I have it set up to point at the IMAP and SMTP servers of my mail provider (FastMail). I also have a google account, and the gmail app works fine for the few bits of mail that go there instead of my regular account.

For my mail accounts, I do an INBOX ZERO like approach (in reality, I’m pretty much nowhere near zero, but today I learned I’m a lot closer than many colleagues). This means I read / respond / do / ignore mail and then move it to an ARCHIVE folder. K9 and Gmail both have the ability to do this easily, so it works well.

Additionally though, I don’t want to care about limits on storage (i.e. expire mail from the server after X days), nor do I want to rely on “the cloud” to be the only copy of things. I also don’t want to have to upload any of past mail I may be keeping around. I also generally prefer to use notmuch as a mail client on a computer.

For those not familiar with notmuch, it does tags on mail in Maildir, is extremely fast and can actually cope with a quantity of mail. It also has this “archive”/INBOX ZERO workflow which I like.

In order to get mail from FastMail and Gmail onto a machine, I use offlineimap. An important thing to do is to set “status_backend = sqlite” for each Account. It turns out I first hacked on sqlite for offlineimap status a bit over ten years ago – time flies. For each Account I also set presynchook = ~/Maildir/maildir-notmuch-presync (below) and a postsynchook = notmuch new. The presynchook is run before we sync, and its job is to move files around based on the tags in notmuch and the postsynchook lets notmuch catch any new mail that’s been fetched.

My maildir-notmuch-presync hook script is:

#!/bin/bash
notmuch search --output=files not tag:inbox and folder:fastmail/INBOX|xargs -I'{}' mv '{}' "$HOME/Maildir/INBOX/fastmail/Archive/cur/"

notmuch search --output=files folder:fastmail/INBOX and tag:spam |xargs -I'{}' mv '{}' "$HOME/Maildir/INBOX/fastmail/Spam/cur/"
ARCHIVE_DIR=$HOME/Maildir/INBOX/`date +"%Y%m"`/cur/
mkdir -p $ARCHIVE_DIR
notmuch search --output=files folder:fastmail/Archive and date:..90d and not tag:flagged | xargs -I'{}' mv '{}' "$ARCHIVE_DIR"

# Gmail
notmuch search --output=files not tag:inbox and folder:gmail/INBOX|grep 'INBOX/gmail/INBOX/' | xargs -I'{}' rm '{}'
notmuch search --output=files folder:gmail/INBOX and tag:spam |xargs -I'{}' mv '{}' "$HOME/Maildir/INBOX/gmail/[Gmail].Spam/cur/"

So This keeps 90 days of mail on the fastmail server, and archives older mail off into month based archive dirs. This is simply to keep directory sizes not too large, you could put everything in one directory… but at some point that gets a bit silly.

I don’t think this is all the most optimal setup I could have, but it does let me read and answer mail on my phone and desktop (as well as use a web client if I want to). There is a bit of needless copying of messages by offlineimap under certain circumstances, but I don’t get enough personal mail for it to be a problem.

Installing Windows on a USB key

For some unknown reason, the Windows installer doesn’t let you install to a USB key. Luckily, there’s a simple workaround. It turns out that only the very first step of installation cares about that. So, if you can fool it (say, by running in qemu), you can have a USB key with a Windows install rather than having to dual boot on your hard disk (e.g. if you run Linux and want all that fast in-built SSD space for Linux)

  1. Download the Windows Installer: https://www.microsoft.com/en-au/software-download/windows10ISO
  2. Start the installer in a VM, with the USB key passed through to the VM as the hard disk (or use a disk image the same size as your USB key for transfer with a utility such as ‘dd’ later). e.g. do:
    qemu-img create -f raw win-installed.img 50G

    qemu-system-x86_64 --enable-kvm -m 8G -cdrom Downloads/Win10_1709_English_x64.iso -hda win-installed.img -boot d
  3. At the first reboot of the installer, instead of letting it boot, stop the VM. You are going to copy the install at this state to the USB key.
  4. Boot from the USB key, go through the rest of the installer. You’re done!

Updating Intel Management Engine firmware on a Lenovo without a Windows Install

This is how I updated my Intel ME firmware on my Lenovo X1 Carbon Gen 4 (reports say this also has worked for Gen5 machines). These instructions are pretty strongly inspired by https://news.ycombinator.com/item?id=15744152

Why? Intel security advisory and CVE-2017-5705, CVE-2017-5708, CVE-2017-5711, and CVE-2017-5712 should be reason enough.

You will need:

  • To download about 3.5GB of stuff
  • A USB key
  • Linux installed
  • WINE or a Windows box to run two executables (because self extracting archives are a thing on Windows apparently)
  • A bit of technical know-how. A shell prompt shouldn’t scare you too hard.

Steps:

  1. Go to https://www.microsoft.com/en-au/software-download/windows10ISO and download the 32-bit ISO.
  2. Mount the ISO as a loopback device (e.g. by right clicking and choosing to mount, or by doing ‘sudo mount -o loop,ro file.iso /mnt’
  3. Go to Lenovo web site for Drivers & Software for your laptop, under Chipset, there’s ME Firmware and Software downloads You will need both. It looks like this:
  4. Run both exe files with WINE or on a windows box to extract the archives, you do not need to run the installers at the end.
  5. you now need to extract the management engine drivers. You can do this in  ~/.wine/drive_c/DRIVERS/WIN/AMT, with “cabextract SetupME.exe” or (as suggested in the comments) you can use the innoextract utility (from linux) to extract them (a quick check shows this to work)
  6. Save off HECI_REL folder, it’s the only extracted thing you’ll need.
  7. Go and install https://wimlib.net/ – we’re going to use it to create the boot disk. (it may be packaged for your distro).
    If you don’t have the path /usr/lib/syslinux/modules/bios on your system but you do have /usr/share/syslinux/modules/bios – you will need to change a bit of the file programs/mkwinpeimg.in to point to the /usr/share locations rather than /usr/lib before you install wimlib. This probably isn’t needed if you’re installing from packages, but may be requried if you’re on, say, Fedora.
  8. Copy ~/.wine/drive_c/DRIVERS to a new folder, e.g. “winpe_overlay” (or copy from the Windows box you extracted things on)
  9. Use mkwinpeimg to create the boot disk, pointing it to the mounted Windows 10 installer and the “winpe_overlay”:
    mkwinpeimg -W /path/to/mounted/windows10-32bit-installer/ -O winpe_overlay disk.img
  10. Use ‘dd’ to write it to your USB key
  11. Reboot, go into BIOS and turn Secure Boot OFF, Legacy BIOS ON, and AMT ON.
  12. Boot off the USB disk you created.
  13. In the command prompt of the booted WinPE environment, run the following to start the update:
    cd \
    cd HECI_REL\win10
    drvload heci.inf
    cd \
    cd win\me
    MEUpdate.cmd

    It should look something like this:

  14. Reboot, go back into BIOS and change your settings back to how you started.

op-test-framework: Let’s break the console!

One of the things I’ve been working on fairly quietly is the test suite for OpenPOWER firmware: op-test-framework. I’ve approach things I’m hacking on from the goal of “when I merge patches into skiboot, can I be confident that I haven’t merged something that’s broken existing functionality?”

By testing host firmware, we incidentally (as well as on purpose) test a whole bunch of BMC functionality. One bit of functionality we rely on a lot is the host “serial” console. Typically, this is exposed to the user over IPMI Serial Over LAN (SOL), or on OpenBMC it’s also exposed as something you can ssh to (which proves to be both faster and more reliable than IPMI, not to mention there’s some remote semblance of security).

When running through some tests, I noticed something pretty odd, it appeared as though we were sometimes missing some console output on larger IOs. This usually isn’t a problem as when we’re using expect(1) (or the python equivalent pexpect) we end up having all sorts of delays here there and everywhere to work around all the terrible things you hope you never learn. So… how could I test that? Well.. what about checking the output of something like dd if=/dev/zero bs=1024 count=16|hexdump -C to see if we get the full output?

Time to add a test to op-test-framework! Adding such a test is pretty easy. If we look at the source of the test I added, we can see what happens (source here).

class Console():
    bs = 1024
    count = 8
    def setUp(self):
        conf = OpTestConfiguration.conf
        self.bmc = conf.bmc()
        self.system = conf.system()

    def runTest(self):
        self.system.goto_state(OpSystemState.PETITBOOT_SHELL)
        console = self.bmc.get_host_console()
        self.system.host_console_unique_prompt()
        bs = self.bs
        count = self.count
        self.assertTrue( (bs*count)%16 == 0, "Bug in test writer. Must be multiple of 16 bytes: bs %u count %u / 16 = %u" % (bs, count, (bs*count)%16))
        try:
            zeros = console.run_command("dd if=/dev/zero bs=%u count=%u|hexdump -C -v" % (bs, count), timeout=120)
        except CommandFailed as cf:
            self.assertEqual(cf.exitcode, 0)
        self.assertTrue( len(zeros) == 3+(count*bs)/16, "Unexpected length of zeros %u" % (len(zeros)))

First thing you’ll notice is that this looks like a Python unittest. It’s because it is. The unittest infrastructure was a path of least resistance, so we started with it. This class isn’t the one that’s actually run, we do a little bit of inheritance magic in order to run the same test with different parameters (see https://github.com/open-power/op-test-framework/blob/6c74fb0fb0993ae8ae1a7aa62ec58e57c0080686/testcases/Console.py#L50)

class Console8k(Console, unittest.TestCase):
    bs = 1024
    count = 8

class Console16k(Console, unittest.TestCase):
    bs = 1024
    count = 16

class Console32k(Console, unittest.TestCase):
    bs = 1024
    count = 32

The setUp() function is pure boiler plate, we grab some objects from the configuration of the test run, namely information about the BMC and the system itself, so we can do things to both. The real magic happens in runTest().

op-test-framework tracks the state of the machine being tested across each test. This means that if we’re executing 101 tests in the petitboot shell, we don’t need to do 101 separate boots to petitboot. The self.system.goto_state(OpSystemState.PETITBOOT_SHELL) statement says “Please ensure the system is booted to the petitboot shell”. Other states include OFF (obvious) and OS, which is when the machine is booted to the OS.

The next two lines ensure we can run commands on the console (where console is IPMI Serial over LAN or other similar connection, such as the SSH console provided by OpenBMC):

console = self.bmc.get_host_console()
self.system.host_console_unique_prompt()

The host_console_unique_prompt() call is a bit ugly, and I’m hoping we fix the APIs so that this isn’t needed. Basically, it sets things up so that pexpect will work properly.

The bit that does the work is the try/except block along with the assertTrue. We don’t currently check that the content is all correct, we just check we got the right *amount* of content.

It turns out, this check is enough to reveal a bug that turns out to be deep in the core Linux TTY layer, and has caused Jeremy some amount of fun (for certain values of fun).

Want to know more about how the console works? Jeremy blogged on it.

Fedora 25 + Lenovo X1 Carbon 4th Gen + OneLink+ Dock

As of May 29th 2017, if you want to do something crazy like use *both* ports of the OneLink+ dock to use monitors that aren’t 640×480 (but aren’t 4k), you’re going to need a 4.11 kernel, as everything else (for example 4.10.17, which is the latest in Fedora 25 at time of writing) will end you in a world of horrible, horrible pain.

To install, run this:

sudo dnf install \
https://kojipkgs.fedoraproject.org//packages/kernel/4.11.3/200.fc25/x86_64/kernel-4.11.3-200.fc25.x86_64.rpm \
https://kojipkgs.fedoraproject.org//packages/kernel/4.11.3/200.fc25/x86_64/kernel-core-4.11.3-200.fc25.x86_64.rpm \
https://kojipkgs.fedoraproject.org//packages/kernel/4.11.3/200.fc25/x86_64/kernel-cross-headers-4.11.3-200.fc25.x86_64.rpm \
https://kojipkgs.fedoraproject.org//packages/kernel/4.11.3/200.fc25/x86_64/kernel-devel-4.11.3-200.fc25.x86_64.rpm \
https://kojipkgs.fedoraproject.org//packages/kernel/4.11.3/200.fc25/x86_64/kernel-modules-4.11.3-200.fc25.x86_64.rpm \
https://kojipkgs.fedoraproject.org//packages/kernel/4.11.3/200.fc25/x86_64/kernel-tools-4.11.3-200.fc25.x86_64.rpm \
https://kojipkgs.fedoraproject.org//packages/kernel/4.11.3/200.fc25/x86_64/kernel-tools-libs-4.11.3-200.fc25.x86_64.rpm \
https://kojipkgs.fedoraproject.org//packages/kernel/4.11.3/200.fc25/x86_64/perf-4.11.3-200.fc25.x86_64.rpm

This grabs a kernel that’s sitting in testing and isn’t yet in the main repositories. However, I can now see things on monitors, rather than 0 to 1 monitor (most often 0). You can also dock/undock and everything doesn’t crash in a pile of fail.

I remember a time when you could fairly reliably buy Intel hardware and have it “just work” with the latest distros. It’s unfortunate that this is no longer the case, and it’s more of a case of “wait six months and you’ll still have problems”.

Urgh.

(at least Wayland and X were bug for bug compatible?)

j-core + Numato Spartan 6 board + Fedora 25

A couple of changes to http://j-core.org/#download_bitstream made it easy for me to get going:

  • In order to make ModemManager not try to think it’s a “modem”, create /etc/udev/rules.d/52-numato.rules with the following content:
    # Make ModemManager ignore Numato FPGA board
    ATTRS{idVendor}=="2a19", ATTRS{idProduct}=="1002", ENV{ID_MM_DEVICE_IGNORE}="1"
  • You will need to install python3-pyserial and minicom
  • The minicom command line i used was:
    sudo stty -F /dev/ttyACM0 -crtscts && minicom -b 115200 -D /dev/ttyACM0

and along with the instructions on j-core.org, I got it to load a known good build.

Books referenced in my Organizational Change talk at LCA2017

All of these are available as Kindle books, but I’m sure you can get 3D copies too:

The Five Dysfunctions of a Team: A Leadership Fable by Patrick M. Lencioni
Leading Change by John P. Kotter
Who Says Elephants Can’t Dance? Louis V. Gerstner Jr.
Nonviolent Communication: A language of Life by Marshall B. Rosenberg and Arun Gandhi
